MaxxECU Pro Premium
MaxxECU Pro Premium
MaxxECU
SKU:Maxx-1624
Regular price
$3,133.22
Regular price
Sale price
$3,133.22
Unit price
/
per
Couldn't load pickup availability
Share
MaxxECU PRO is a product developed from the ground up to be flexible, reliable and fast. MaxxECU PRO gives the user complete engine control!
Fast Facts:
- Up to 12 cylinders sequentially
- 16 injector outputs (low or high impedance injectors)
- 12 ignition outputs
- 12 inputs for exhaust gas temperature sensors (EGT)
- Built in MAP-sensor for boost pressure up to 3bar (400Kpa)
- Built in driver for dual WBO sensors (LSU 4.2 and 4.9 compatible)
- Dual E-Throttle (DBW) support
- Dual knock sensor input
- 16 optional 0-5V inputs
- 6 additional temperature inputs
- 10 additional digital inputs (4 of them can be used with VR sensors)
- 30 auxiliary outputs (GPO), 8 of them +12v outputs
- 2 0-5V output
- 1 5-10v output (sensor output)
- Dual CAN bus
- Waterproof aluminum case
- Connectors, software and settings completely backwards compatible with standard MaxxECU. Easy upgrade
